Casio FX-CG20 User Manual

28
Image Plotter –
Working with Images
With the “Image Plotter”- application, the images or image sequences
can be mathematically analysed. Images and image sequences are
located in large numbers on the calculator.
Image plot- application
If you start the ImagePlot application, the last Image used will appear,
or a white screen with a coordinate system.
[
OPTN
]
All other commands are displayed on OPTN.
To open a file, select
[
F1
] (
FILE
)
and OPEN
Open Images
If the FILE>>OPEN has been selected, the directory structure of the
calculator will be shown.
In the CASIO folder, you will find two folders with image data:
g3b Animates images or image sequences.
g3p Image files
If you have selected an image file, it will open. Now, the coordinate
system can be adjusted using the Cursor keys.
Open Images
• Press the Image plotter application
[
OPTN
]
.
Then more options are available.

Casio FX-CG20 Specifications

General

Type	Graphing
Form factor	Pocket
Product color	Black
Digits	- digits
Display tilting	No
Display number of lines	8 lines
Display number of characters	21
Flash memory	16 MB
Internal memory	0.01562 MB
Battery type	AAA
Power source	Battery
Battery technology	Alkaline
Number of batteries supported	4
USB port	Yes

Weight and Dimensions

Weight	230 g
Dimensions (WxDxH)	89.5 x 20.6 x 188.5 mm
