12
The SPECIAL FUNCTIONS (Fx) for the MIG-MAG manual process correspond to the feeder (when fitted) as follows:
Table B
Special function
PARAMETER DISPLAY
Screen - A
PARAMETER DISPLAY Screen - V Welding mode
Default
Range
TWO STROKE (2T)
FOUR STROKE (4T)
CRATER 2T
CRATER 4T
SPOT WELDING
STITCH WELDING
CYCLE STANDARD
CYCLE ADVANCED
PRE GAS PrG 0.1s (0.0 - 2.0)s ●●●●●●●●
STARTING SPEED StS 0 -30 - +30 ●●●●●●●●
HOT START Hot 0 -30 - +30 ●●●●●●●●
STITCH TIME F05 1.0s (0.1 - 20.0)s ●
STITCH PAUSE F06 1.0s (0.1 - 20.0)s ●
SPOT TIME F07 3.0s (0.1 - 20.0)s ●
INITIAL WIRE SPEED F08 5.0m/min (0.6-MAX)m/min ●● ●●
INITIAL VOLTAGE F09 25.0V (10 - MAX)V ●● ●●
INITIAL CRATER TIME F10 1.0s (0.0 - 20.0)s ●
INITIAL SLOPE F11 1.0s (0.0 - 20.0)s ●● ●●
FINAL SLOPE F12 1.0s (0.0 - 20.0)s ●● ●●
FINAL WIRE SPEED F13 5.0m/min (0.6-MAX)m/min ●● ●●
FINAL VOLTAGE F14 25.0V (10 - MAX)V ●● ●●
FINAL CRATER TIME F15 0.0s (0.0 - 5.0)s ●
BURN BACK bub 0 -30 - +30 ●●●●●●●●
POST GAS PoG 1.0s (0.0 - 10.0)s ●●●●●●●●
FIRST SLOPE ( I1 TO I 2 ) F18 0.05s (0.00 - 2.00)s ●
CYCLE WIRE SPEED F19 5.0m/min (0.6-MAX)m/min ●●
CYCLE VOLTAGE F20 25.0V (10 - MAX)V ●●
SECOND SLOPE ( I 2 TO I 1 ) F21 0.05s (0.00 - 2.00)s ●
SLOPE JOB F28 0.5s (0.1 - 20.0) s ●●●●●●●●
WARNING:
• The STANDARD or ADVANCED welding CYCLE mode can only be activated by opening the ADVANCED SETUP Menu - AD-
VANCED MODE - CYCLE (for further explanations, see the relevant paragraph).
• It is possible to access editing of the SPECIAL FUNCTIONS (Fx) during welding.
•
Some of the values edited will be used immediately by the operator, while others will be active from when the next welding
task begins.
• The HOLD function is not active within the SPECIAL FUNCTIONS Menu (SET UP Fx).
