21
5 - HOLD MMA
When welding ends the fields in the display must show the same values that were displayed during welding, with the difference
that they are now values defined as HOLD. In this phase the VISION S
CREEN
shows the HOLD box highlighted, while on the HT5
panel the HOLD FUNCTION LED flashes until the end of the HOLD Function. If the HOLD Function is Interrupted via a panel (e.g. DH),
it will also be interrupted automatically on the other (HT5) and vice-versa.
“DH” / “VS” CONTROL PANEL
AV
68 7.2
MMA Cr Ni
PROGRAM 3200
HOLD
“HT5” CONTROL PANEL (not used with DH 32 and VS 32)
HOLD Function LED
