50
Error
condition
Error code Error description and possible diagnosis
Err E5.0
MIG PROGRAMS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN ONLY in the event of a fault and NOT in the ERROR LOG Menu.
Err E5.1
PULSED MIG WELDING PROGRAMMES MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN ONLY in the event of a fault and NOT in the ERROR LOG Menu.
Err E5.3
MMA PROGRAMS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN ONLY in the event of a fault and NOT in the ERROR LOG Menu.
Err E5.4
TIG PROGRAMS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN ONLY in the event of a fault and NOT in the ERROR LOG Menu.
Err E5.5
MIG MANUAL PROGRAMS MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Error visible on VISION S
CREEN ONLY in the event of a fault and NOT in the ERROR LOG Menu.
Err E6.0
HT5 CAN LINK MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Err E6.1
ROBOT LINK MISSING
NON automatic reset error.
Immediately contact technical assistance dept.
Err E6.5
NO ROBOT INTERFACE
Automatic reset error.
Err E7.0
RC ANALOGIC MISSING
NON automatic reset error.
Check that the ANALOGIC RC - OBLIGATORY function is included within the ADVANCED SETUP
Menu / EQUIPMENT LAYOUT.
After this initial check you need to know that this error can only occur in the following cases:
• ANALOGIC RC remote control not connected to the relevant connector.
• The welding plant does not recognise the ANALOGIC RC remote control, even though it is
connected correctly.
• The ANALOGIC RC remote control disconnected when the welding plant is working normally.
As soon as the remote control is connected again this error condition resets itself automatically!
If the alarm occurs even when the ANALOGIC RC - OPTIONAL function is included in the
ADVANCED SETUP Menu / EQUIPMENT LAYOUT, call Technical Assistance Department
immediately.
Err E8.3
NO GAS FLOW
Error reset by a command from the robot’s board (see robot interface manual).
Err E8.4
NO H2O FLOW
Error reset by a command from the robot’s board (see robot interface manual).
Err E8.7
NO WELDING WIRE
Error reset by a command from the robot’s board (see robot interface manual).
AUT ADJ
POWER LIMITATION
This alarm appears if the power limit is exceeded. The alarm alternates with the standard display
every 1.5 seconds, despite which the machine continues to weld, supplying limited power, but
complying with the values shown on the data plate.
The table provides a simple summary of all the error conditions that may arise on the welding plant and, if possible, what the op-
erator must do to attempt to resolve the problem.
The table includes 2 types of errors:
•
Automatic reset error: Once the alarm condition has been resolved the welding machine starts working again and the opera-
tor can weld again! The VISION SCREEN goes back to exactly the same point it was at prior to signalling the alarm!
PLEASE NOTE: After resetting has been completed, during normal operation of the machine, the VISION S
CREEN will still show
the error signal to inform the operator of the event ( ), but this can be removed visually from the display by simply pushing
the MENU KEY.
WARNING: This only removes the visual error indication but not the history of what happened!
•
NON automatic reset error: To remove the alarm status and reinstate correct operation of the machine, the welding plant
must be switched off.
The machine will then be working again and the operator can weld again!
