43
A
ChargePoint Gateway
Installation Guide
A ChargePoint Gateway consists of a cellular LTE modem for wide area networking, and built-in WiFi
for local communications to and from CPF50 charging stations.
Specifications
Basic specifications for the ChargePoint Gateway are shown in the table below.
For detailed specifications, refer to the ChargePoint Gateway Data Sheet at:
https://chargepoint.com/support/guides.
Requirements
Before installing the ChargePoint Gateway, choose an appropriate location by considering the
following:
Important: The ChargePoint Gateway must be located where cellular signals are optimum
for LTE service, and each ChargePoint Gateway must be located within 45 m (150 ft) line-of-
sight to the CPF50 charging stations. Each CPF50 charging station has built-in WiFi
capability to communicate with the ChargePoint Gateway to access ChargePoint network
services.
Rating Class II
Input Power < 4 W
Input Current < 0.4 A using single-phase 110/120 V, or
< 0.2 A using single-phase 208 V service
Input Terminals 100-240 VAC, universal
Physical Placement 0.6-1.2 m (2-4 ft) from CPF50 charging station(s)
1.8-2.4 m (6-8 ft) above floor level
Connectivity Supports 1-9 CPF50 charging stations
Connectivity
Placement
< 30.5-45.7 m (100-150 ft) line-of-sight to associated charging stations
