Mount a Dual Station Bracket and
CMK
Prepare the CMK
1. Position the CMK packaging so its bottom is located near where the charging station will be
installed.
Note: Do not unwrap the ropes.
2. Remove and discard the two shipping screws (a)
from the front of the CMK.
3. Remove the cardboard packaging.
Mount the Bracket and CMK
1. Slide the bottom internal brace over the pedestal, guiding it
gently to the bottom.
Important: Do not tilt or carry the assembly with
the top end lower than the bottom end. When
you remove the shipping screws, the
counterweights are free to move in either
direction.
