Operating Principles Edge Maxx
5-8
Electrical Panel I/O Control Panel
All control components are located in the I/O
control panel (Figure 5-5) in the right endframe.
The table on the next page provides an explanation
of each item indicated in the picture.
PO3
P02
TERM
Figure 5-6: Control components in the electrical panel.
COMM
PO1
INT SENSORS
CLMP
MOTION
ANLG
To Next Page
