Edge Maxx Operating Principles
5-9
MAIN ELECTRICAL PANEL CONTROL COMPONENTS
Module Description
ANLG Analog Output (Motion Control)
CLMP Clamp Control
COMM Communications Head - CHI Panel Interface
INT Interlocks
MOTION Motion Control
PO1-PO2-PO3 DC Power Supplies
SENSORS Sensor Inputs
TERM Terminal Block
