[DB600] General Instruction Manual Operation screen (constant value operation)
- 45 -
□□□□
▲ SEL ↑ ↓ ▼ SEL
Timer
Timer 1 elapsed time
Displays the elapsed time of timer 1.
"
□□□□
"
to
" "
Timer 1 elapsed time [Second]
This display is available when "Timer 1" is assigned to "External input (MODEd)" for
the specification with external signal input.
Setting/changing using the [

] or [

] key is unavailable.
The timer time will be updated when the external signal input of timer 1 is turned ON
(conduction state).
The timer time will be reset to 0 second when the external signal input of timer 1 is
turned OFF (non-conduction state).
Turning OFF the power will reset the time to 0 second.
[Switch to operation initial screen]
Press and hold the [MODE] key to display the screen set on the MODEt operation
initial screen.
[AUTO/MANUAL output switch]
Press and hold the [>] key to switch the output between AUTO and MANUAL.
When switch to the MANUAL output, it will be switched to the PV/OUT1 (operation
screen) automatically.
□□□□
▲ SEL ↑ ↓ ▼ SEL
Timer 2 elapsed time
Displays the elapsed time of timer 2.
"
□□□□
"
to
" "
Timer 2 elapsed time [Second]
This display is available when "Timer 2" is assigned to "External input (MODEd)" on
the instrument with external signal input specification.
Setting/changing using the [

] or [

] key is unavailable.
The timer time will be updated when the external signal input of timer 2 is turned ON
(conduction state).
The timer time will be reset to 0 second when the external signal input of timer 2 is
turned OFF (non-conduction state).
Turning OFF the power will reset the time to 0 second.
[Switch to operation initial screen]
Press and hold the [MODE] key to display the screen set on the MODEt operation
initial screen.
[AUTO/MANUAL output switch]
Press and hold the [>] key to switch the output between AUTO and MANUAL.
When switch to the MANUAL output, it will be switched to the PV/OUT1 (operation
screen) automatically.
