Format Cables Frame rate (Hz) Sampling Bit-depth Notes
3840x2160 4 48, 50, 60 Y'C'
B
C'
R
/RGB/
4:4:4:(4)
10 bpc Y'C'
B
C'
R
/RGB
component at
quad-link 6 Gb/s
(ST 2081-12)
mode 2 structure
II
3840x2160 4 48, 50, 60 Y'C'
B
C'
R
/RGB/
4:4:4
12 bpc Y'C'
B
C'
R
/RGB
component at
quad-link 6 Gb/s
(ST 2081-12)
mode 2 structure
III
3840x2160 4 48, 50, 60 Y'C'
B
C'
R
/4:2:2 12 bpc Y'C'
B
C'
R
component at
quad-link 6 Gb/s
(ST 2081-12)
mode 2 structure
IV
3840x2160 4 48, 50, 60 Y'C'
B
C'
R
/4:2:2:4 12 bpc Y'C'
B
C'
R
component at
quad-link 6 Gb/s
(ST 2081-12)
mode 2 structure
IV
Quad-link HFR 2D 2SI image formats
The following quad-link SDI 2D 2SI image formats are supported.
Format Cables Frame rate (Hz) Sampling Bit-depth Notes
4K 3840x2160 4 96, 100, 120 Y'C'
B
C'
R
/4:2:2 10 bpc Y'C'
B
C'
R
component at
quad-link 6 Gb/s
(ST 2081-12)
mode 3
3840x2160 4 96, 100, 120 Y'C'
B
C'
R
/RGB/
4:4:4:(4)
10 bpc Y'C'
B
C'
R
/RGB
component at
quad-link 12 Gb/s
(ST 2082-12)
mode 2 structure
II
3840x2160 4 96, 100, 120 Y'C'
B
C'
R
/RGB/
4:4:4
12 bpc Y'C'
B
C'
R
/RGB
component at
quad-link 12 Gb/s
(ST 2082-12)
mode 2 structure
III
Video Input panel
CineLife+ User Guide 36
020-103073-10 R
ev. 1 (02-2023)
