Format Cables Frame rate (Hz) Sampling Bit-depth Notes
3840x2160 4 96, 100, 120 Y'C'
B
C'
R
/4:2:2:(4) 12 bpc Y'C'
B
C'
R
component at
quad-link 12 Gb/s
(St 2082-12)
mode 2 structure
IV
Quad-link square-division 2D image formats
The following quad-link 2D SDI image formats are supported in square division mapping format, so
each SDI input shall represent one quarter of the total image assigned as shown in the following
diagram:
Input 1
SDI 1
Input 2
SDI 2
Input 3
SDI 3
Input 4
SDI 4
Format Cables Frame rate (Hz) Sampling Bit-depth Notes
4K 3840x2160 4 24, 25, 30 Y'C'
B
C'
R
/RGB/
4:4:4:(4)
10 bpc Y'C'
B
C'
R
/RGB
component at
quad-link 3 Gb/s
(ST 425-5) annex
B square division
of 2160-image
formats, B
.1 level
A mapping
3840x2160 4 24, 25, 30 Y'C'
B
C'
R
/RGB/
4:4:4
12 bpc Y'C'
B
C'
R
/RGB
component at
quad-link 3 Gb/s
(ST 425-5) annex
B square division
of 2160-image
formats, B.1 level
A mapping
3840x2160 4 24, 25, 30 Y'C'
B
C'
R
/4:2:2:4 12 bpc Y'C'
B
C'
R
component at
quad-link 3 Gb/s
(ST 425-5)
structure annex B
square division of
2160-image
formats B.1 level
A mapping
3840x2160 4 24, 25, 30 Y'C'
B
C'
R
/4:2:2 12 bpc Y'C'
B
C'
R
component at
quad-link 3 Gb/s
Video Input panel
