Chroma 19032 - Description of New IEEE-488.1 Commands

Electrical Safety Analyzer 19032 User’s Manual
6-2
33
PSTR (?)
{String}
Sets Pause Mode Message
34
MEAS: STEPnnn?
X
Reads the test result data for specified STEP
35
GTEC
X
Starts GET Cs function of OSC Mode
36
DWLL (?)
{f ¦*}
Sets DWELL time
37
LACHI (?)
{f ¦*}
Sets LAC High Limit(for 6000-08 only)
38
LADHI (?)
{f ¦*}
Sets LDC High Limit (for 6000-08 only)
39
DISP (?) {n ¦c}
Displays RMS or PEAK for LC leakage
current (for 6000-08 only)
40
FALL (?)
{f ¦*}
Sets voltage fall time
41
IRRNG (?)
{n ¦c}
Selects IR mode range
Note
1. Parameter descriptions:
x: no parameter required c: indicates a mnemonic
n: indicates an integer *: indicates the " * " ASCII character
2. The CHEC(?) of IEEE-488.1 command is deleted.
6.3 Description of New IEEE-488.1 Commands
1. MODE(?) {n¦c}
Function : Set MODE
Parameter : Use either the mnemonic or the Mode number.
Test Mode
Mnemonic
No.
GB grounding resistance
GR or G
0
AC Hi-Pot
WA or A
1
DC Hi-Pot
WD or D
2
IR isolation resistance
IR or I
3
LC leakage current
LC or L
4
PAUSE
PA or P
5
OSC open/short detection
OS or O
6
Description: If the test mode is changed, other test items will be cleared at the same time
and become the initial value.
2. HILI(?) {f ¦*}
Function : Set High Limit value
Parameter : 1. "*": disable High Limit testing.
: 2. “f”: refer to each specification. Ex. 9032C
GR Mode
f = 0.1 ~ 510.0 mΩ
WV Mode
f = 0.01 ~ 40.00 mA
WD Mode
f = 0.01 ~ 12.00 mA
IR Mode
f = 1 ~ 9999 MΩ
LC Mode
f = 0.001 ~ 9.999 mA(Max)
OSC Mode
OPEN CHK.=0(OFF), 100%~500%
Description:
1. This command is disabled when running in IR Mode
2. If the High Limit is smaller than the Low Limit, the Low Limit will be disabled
under WV and WD Mode.
