Chroma 19032 - Auto Mode Setting

Descriptions of Panel
4-35
with the standard capacitance value [Cs]).
05. CHNL (H-L): The same as AC/DC CHANNEL setting.
4.17.2 Auto Mode Setting
STEP 1: GB
STEP SETTING
01.
TEST STEP :
1
UP
02.
TEST MODE :
GB
03.
CURRENT :
3.00 A
04.
HIGH LIMIT :
100.0 mΩ
05.
LOW LIMIT :
OFF
DOWN
06.
TEST TIME :
3.0 sec
07.
TWIN PORT :
OFF
08.
CHNL(H-L) :
INSERT
DELETE
SELECT STEP
Remote
Lock
Offset
Error
STEP 2: AC
STEP SETTING
01.
TEST STEP :
2
UP
02.
TEST MODE :
AC
03.
VOLTAGE :
0.050 KV
04.
HIGH LIMIT :
0.500 mA
05.
LOW LIMIT :
OFF
DOWN
06.
ARC LIMIT :
OFF
07.
ARC FILTER :
3-230 kHz
08.
TEST TIME :
3.0 sec
09.
RAMP TIME :
OFF
INSERT
10.
FALL TIME :
OFF
11.
CHNL(H-L) :
OFF
DELETE
SELECT STEP
Remote
Lock
Offset
Error
STEP 3: IR
STEP SETTING
01.
TEST STEP :
3
UP
02.
TEST MODE :
IR
03.
VOLTAGE :
0.050 KV
04.
LOW LIMIT :
0.1 MΩ
05.
HIGH LIMIT :
OFF
DOWN
06.
TEST TIME :
3.0 sec
07.
RAMP TIME :
OFF
08.
FALL TIME :
OFF
09.
RANGE :
AUTO
INSERT
10.
CHNL(H-L) :
OFF
DELETE
SELECT STEP
Remote
Lock
Offset
Error
