Chroma 19032 - 4 Description of Panel; Front Panel

Descriptions of Panel
4-1
4. Description of Panel
4.1 Front Panel
2
3
1
8 9
11 5 6 7
4 10 13 14
15
16
12
Key Area Terminal AreaDisplay AreaKey Area
Figure 4-1
Figure 4-1 illustrates the controls and indicators on the front panel of the Electrical Safety
Analyzer.
 Display Area Magnification
MAIN MENU
1 -> SYSTEM
2 -> OPTION
3 -> CALIBRATION
4 -> KEY LOCK
5 -> NEW SECURITY CODE
6 -> FAIL LOCK
7 -> ERROR LOG
MEMORY
PRESET
PROGRAM
TEST
Remote
Lock
Offset
Error
Title List
Function key message display
Message Bar
Message Indication
