Chroma 19032 - Page 42

Electrical Safety Analyzer 19032 User’s Manual
4-12
Preset parameter function description table:
No.
Setting Item
Range
Initial Setting
Description
01 Pass Hold
0.2∼99.9s
0.5
Length of time the PASS buzzer sounds and
the Pass Relay on the Remote I/O will
remain closed.
02 Step Hold
0.1∼99.9s /
KEY
0.2
Time interval between test procedure steps.
KEY: Requires [START] key to be pressed
before continuing to the next test step.
03
AC Freq.
50-600Hz
60
Frequency (Hz) of output voltage when
running AC withstand test.
04
GB Freq.
50, 60Hz
60
Frequency (Hz) of output current when
testing ground impedance.
05
IEC-601-1
ON/OFF
OFF
When the setting is ON:
Test will initially apply ½ the programmed
test voltage, then gradually apply a linear
ramp to the test voltage over the
programmed ramp time until the required
test voltage is achieved. It then holds the
voltage for the programmed test time then
ramps back down identical to the ramp up
(see waveform shown in Note 1.)
06 GB Voltage
6.0∼9.0V
9.0
Open circuit voltage during ground bond
testing.
07 Auto Range ON/OFF OFF
Sets withstand voltage auto-range function
On or Off
08 Soft. AGC ON/OFF ON
Sets software auto gain compensation
function On or Off.
09 Part No.
Not over 13
characters
Blank
Assigns a part number to the device under
test.
10 Lot No.
Not over 13
characters
Blank
Assigns a lot number to the device under
test.
11
Serial No.
(Note 2)
Not over 13
characters
Blank
Assigns a serial number to the device under
test.
12
Start Wait
0.1~99.9s /
OFF
OFF
Delay time – after connection to the device
is made and before current is applied to
begin the ground bond test
13 Ramp Judg. ON / OFF ON
If Ramp Judg. Is set to ON, it will judge if the
current value is over the High Limit setting
value as the Ramp time is executed.
If Ramp Judg. Is set to OFF, it will not
judge
if the current value is over the High Limit
setting value as Ramp time is executed.
Note
1. When IEC-601-1 is set to ON, the output voltage waveform follows the pattern as
shown below.
