HIPOT Tester 19051/19052/19053/19054 User’s Manual
modes are as below descriptions.
(1) When users press START KEY, the
program judge if DUT connected
well by GR CONT. ON or OFF.
(2) If CR CONT. judge DUT is
connected well then proceed test
automatically when set TIME is up.
(3) After the test is ended, re-judge if
CR CONT. is continue for the
condition of proceeding test.
Soft. AGC ON/OFF ON Set software automatic gain compensation
function is open or not.
Auto Range ON/OFF OFF Set withstand voltage auto-range function is
open or not.
GFI ON/OFF ON Set ground fail interrupt function
AFTER FAIL STOP/CONTINUE/R
ESTART
STOP After setting FAIL, it indicates if stop the test
or continue to the next step or restart.
SCREEN ON/OFF ON Set if show test screen.
SMART KEY ON/OFF OFF Set if open parameter memory function.
RAMP JUDG. ON/OFF ON When set this item to ON, it means during
ramp time will judge high limit under DC
mode.
When set this item to OFF, it means during
ramp time won’t judge high limit under DC
mode.
Part No. Not over 13
characters
None Set the product Part No.
Lot No. Not over 13
characters
None Set the product Lot No.
Serial No. Not over 13
characters
None Set the product serial no. format, * means
changeable character.
4.7 PROGRAM Setting
4.7.1 Test Procedure Setting
1. Under power on menu, press Function Key PROGRAM and then enter PROGRAM
setting menu as the following:
LOW : 0.001mA
STEP 1 DC
ARC : OFF
UP
VOLT:0.050kV RAMP : 999.0s
HIGH:0.500mA FALL : OFF
MORE..
TIME : 3.0s CHK : OFF
ENTER
DWLL: OFF 1 2 3 4 5 6 7 8
SCAN : X X X X X X X X
EXIT
PROCESS STEP RMT LOCK OFST ERR
4-8
