HIPOT Tester 19051/19052/19053/19054 User’s Manual
3. Before ending the test previous 0.6 sec., the tested current is shown and auto range to
low current as the Site 1 in the following menu.
STEP 1/1 AC LOW : OFF
ARC : OFF
PROGRAM
0.050kV
RAMP : OFF
FALL : OFF
PRESET
0.500mA
REAL : OFF
1 2 3 4 5 6 7 8
MENU
0.3s
SCAN : X X X X X X X X
RMT LOCK OFST ERR
MORE..
4.9 KEY LOCK Function
4.9.1 KEY LOCK Setting Method
1. Under power on menu, if "LOCK" text block isn’t highlighted then can set KEY LOCK
function.
2. Press Function Key MENU then show the following menu:
1. MEMORY
UP
2. SYSTEM
3. OPTION
DOWN
4. CALIBRATION
5. KEY LOCK
SELECT
SELECT FUNC. RMT LOCK OFST ERR
EXIT
3. Move the highlighted to "KEY LOCK " by using Function Keys UP, DOWN. Press
Function Key SELECT to enter KEY LOCK setting menu.
4. Using Function Keys A, B to input PASSWORD (please input AAAA, when PASSWORD
is not set).
5. Press ENTER key will show selection window, "LOCK" text block will show highlighted.
The user can use Function Keys YES, NO to select whether LOCK MEMORY RECALL
function together or not.
6. Press Function Keys EXIT to complete KEY LOCK function.
4.9.2 KEY LOCK Release Method
1. Under power on menu, if "LOCK" text block is highlighted then can release KEY LOCK
function.
2. Press Function Key MENU then show the following menu:
Site 1
4-16
