HIPOT Tester 19051/19052/19053/19054 User’s Manual
then will show S-KEY word on the lower left side of screen. At this time, the adjustment
function of UP and DOWN keys is disabled and read back the previous test parameter.
If want to recover the adjustment function of UP and DOWN keys, press ENTER key
continuous for one second until S-KEY word on the lower left side of screen is
disappeared.
4.7.4 Each Parameter Setting Data Description
The following described parameter setting data of each test mode.
AC withstand voltage test mode
LOW : 0.001mA
STEP 1 AC
ARC : OFF
UP
VOLT:0.050kV RAMP : 999.0s
HIGH:0.500mA FALL : OFF
DOWN
TIME : 3.0s REAL : OFF
1 2 3 4 5 6 7 8
ENTER
SCAN : X X X X X X X X
SELECT MODE RMT LOCK OFST ERR
EXIT
VOLT : Setting withstand voltage test needed voltage.
HIGH : Setting leakage current high limit value.
TIME : Setting test needed time, input 0 means continuous test.
LOW : Setting leakage current low limit value, input 0 means OFF.
ARC : Setting arc high limit, input 0 means OFF.
RAMP : Step-up setting voltage needed time, input 0 means OFF.
FALL : The needed time is from setting voltage value to zero, 0 means OFF.
REAL : Setting real leakage current high limit value, input 0 means OFF.
SCAN : Setting scan test selection point.
DC withstand voltage test mode
LOW : 0.001mA
STEP 1 DC
ARC : OFF
UP
VOLT:0.050kV RAMP : 999.0s
HIGH:0.500mA FALL : OFF
DOWN
TIME : 3.0s CHK : OFF
DWLL: OFF 1 2 3 4 5 6 7 8
ENTER
SCAN : X X X X X X X X
SELECT MODE RMT LOCK OFST ERR
EXIT
VOLT : Set withstand voltage test needed voltage.
HIGH : Set leakage current high limit value.
TIME : Set test needed time, input 0 means continuous test.
DWLL : Set DWELL needed time, 0 means OFF.
(During DWELL TIME action don’t judge high and low limit value of leakage
current but the limit don’t over high limit of setting range.)
LOW : Set leakage current low limit value, input 0 means OFF.
ARC : Set arc high limit, input 0 means OFF.
4-10
