Panel Description
RAMP : Step-up setting voltage needed time, input 0 means OFF.
FALL : The needed time is from setting voltage value to zero, 0 means OFF.
CHK : Select detect charge current over low (CHECK LOW)
SCAN : Set scan test selection point.
IR Insulation resistance test mode
HIGH : OFF
STEP 1 IR
RAMP : OFF
UP
VOLT : 0.050kV FALL : OFF
LOW : 1.0MΩ RNG : AUTO
DOWN
TIME : 3.0s 1 2 3 4 5 6 7 8
SCAN : X X X X X X X X
ENTER
SELECT MODE RMT LOCK OFST ERR
EXIT
VOLT : Set insulation resistance test needed voltage.
LOW : Set insulation resistance low limit value.
TIME : Set test needed time, input 0 means continuous test.
HIGH : Set insulation resistance high limit value, input 0 means OFF
RAMP : Step-up setting voltage needed time, input 0 means OFF.
FALL : The needed time is from setting voltage value to zero, 0 means OFF.
RNG : Set the current test range of insulation resistance, AUTO means automatic
switch range. The relation of current range and resistance measurement range
is as below table shown.
IR Display Value
Range
Setting Voltage
50V ~ 250V
Setting Voltage
250V ~ 1000V
10mA(3~10mA) 0.10MΩ~0.10MΩ 0.10MΩ~1.00MΩ
3mA(0.3~3mA) 0.10MΩ~0.90MΩ 0.10MΩ~3.50MΩ
300uA(30~300uA)
0.10MΩ~9.00MΩ 0.10MΩ~25.00MΩ
22.0MΩ~35.0MΩ
30uA(3~30uA)
0.10MΩ~25.00MΩ
22.0MΩ~90.0MΩ
0.10MΩ~25.00MΩ
22.0MΩ~250.0MΩ
0.220GΩ~0.350GΩ
3uA(0.3~3uA)
22.0MΩ~250.0MΩ
0.220GΩ~0.900GΩ
25.0MΩ~250.0MΩ
0.220GΩ~2.500GΩ
2.20GΩ~3.33GΩ
300nA(20~300nA)
0.200GΩ~2.000GΩ 0.200GΩ~2.500GΩ
2.20GΩ~50.00GΩ
Note
Select IR suitable current range please follows test voltage and DUT insulation
resistance for counting the quantity of current then follows it to select suitable
current range.
SCAN : Set scan test selection point.
4-11
