GPIB Operation Description (Option)
5. GPIB Operation Description (Option)
5.1 Guide
The user can use computer by GPIB (IEEE 488-1978) interface to remote control and data
transfer.
5.2 Interface Specification
5.2.1 Adaptable Standard
IEEE488-1978 standard
5.2.2 Interface Capability
Code Meaning
SH1
Source Handshake
Equipped with source handshake interface function
AH1
Acceptor Handshake
Equipped with acceptor handshake interface
function
T4
Basic Talker requirement
Equipped with basic talker interface function
L4
Basic Listener requirement
Equipped with basic listener interface function
SR1
Service request requirement
Equipped with service request interface function
RL1
All remote/local requirement
Equipped with remote/local interface function
PP0
No Parallel poll requirement
No parallel poll interface function
DC1
All device clear requirement
Equipped with device clear interface function
DT0
No Device trigger requirement
No device trigger interface function
C0
No controller requirement
No controller interface function
5.2.3 Using Code
ASCII code
5-1
