HIPOT Tester 19051/19052/19053/19054 User’s Manual
Short/Open Circuit detection test mode (OS)
OPEN CHK : 50%
STEP 1 OS
SHORT CHK : 300%
UP
1 2 3 4 5 6 7 8
SCAN : X X X X X X X X
DOWN
ENTER
SELECT MODE RMT LOCK OFST ERR
EXIT
OPEN CHK : Set the judgment test result to open condition(compare the test reading with
the read standard capacitance value [Cs]).
SHORT CHK : Set the judgment test result to short condition(compare the test reading with
the read standard capacitance value [Cs]).
SCAN : Set the scanning test selection point.
Pause Mode
STEP 1 PA
UP
MESSAGE : PAUSE MODE
UNDER TEST SIGNAL : OFF
DOWN
TIME : CONT.
ENTER
SELECT MODE RMT LOCK OFST ERR
EXIT
MESSAGE: Set the message shows on pause screen, the maximum input character is 15.
UNDER TEST SIGNAL: Set UNDER TEST signal on rear panel when pause and DANGER
LED action.
(1) Set to ON: UNDER TEST terminal on rear panel is short circuit
under pause mode. DANGER LED on panel is blinking.
(2) Set to OFF: UNDER TEST terminal on rear panel is open circuit
under pause mode. DANGER LED on panel isn’t
blinking.
TIME: Set the method of PAUSE MODE.
(1) Set to CONT: Pause mode is ended until press START on panel
or START signal re-triggered on rear panel.
(2) Set to 0.3~999sec: Pause mode is ended until setting time’s up.
4.8 How to Process Test
4.8.1 Offset Value Calibration Confirmation of Test Cable
1. Under power on menu, press Function Key MORE.. to enter multi sets of STEPS test
menu.
4-12
