HIPOT Tester 19051/19052/19053/19054 User’s Manual
6. No good judgment
If the measurement value is abnormal, the main unit is judged as FAIL and stop to output
immediately. The rear panel outputs FAIL signal, the buzzer functions simultaneously.
Keep on function until STOP key of the main unit be pressed. The test result will show
no good status.
Test result Meaning
HI Measurement current / Resistance value over high limit
LO Measurement current / Resistance value over low limit
ARC Current arc over high limit
CHECK LOW Charging current over low
ADV OVER Voltage / current reading over hardware valid digit.
ADI OVER Current / resistance reading over hardware valid digit.
GR CONT. Grounding on test no good
GFI TRIP Ground fail interrupt
AC REAL HI Real current measurement value over high limit
Under any circumstances only need to press STOP key if you want to stop the test output.
4.8.3.2 OS Test Procedure
1. Connection is completed correctly by connecting DUT device method under standby
menu.
2. Under standby menu (as the following figure):
STEP 1/1 OS OPEN CHK : 50%
SHORT CHK : 300%
PROGRAM
0.100kV
1 2 3 4 5 6 7 8
SCAN : X X X X X X X X
PRESET
0.000nF
MENU
0.1s
STANDBY RMT LOCK OFST ERR
MORE..
Line 1
Line 2
Line 3
Schema:
OS means the test mode is short/open detection mode. "Site 1" means the setting
voltage value, "Site 2" means the capacitance value which be read, "Site 3" means the
test time. The test results are shown on the status list.
3. Please press STOP key, ready for testing, the status list shows "STANDBY".
4. Please press F4 MORE.. key to switch the menu which be displayed.
VOLTAGE MEASURE REAL
1 OS 0.100kV 0.000nF -------------
OFFSET
GET Cs
1 2 3 4 5 6 7 8
SCAN: X X X X X X X X
STANDBY RMT LOCK OFST ERR
MORE..
4-14
