Automatic Transformer Test System 3300/3302 User’s Manual
BEEPER:
To select the volume of the buzzer. The value is being set on "SMALL ". The selectors are
"L(large) " and "S(small) ". The procedure is to move the cursor to the right of BEEPER by
pressing and adjust it by pressing [L], [S] and [OFF].
GPIB ADDRESS: (Reserved function)
To select the GPIB address. The value is being set on "03". The range is from "00
〜
30".
The procedure is to move the cursor to the right of the GPIB ADDRESS by pressing
and adjust it by pressing [ ] and [ ].
TEST FOR:
To select the automatic scan test whether measure the value of each set windings, because in
the automatic scan test function, if the user just set the pins of transformer every windings,
but not set every winding standard, then will not measure the windings those have not set
standard value, but if set this "TEST FOR" function, then just set the pins of windings, then
automatic measure the windings. The initial value is "OFF", then the range is ON/OFF two
choices, use the keys cursor to select, the black area will move to right side the "TEST FOR"
press key [ON] and [OFF] which beside the screen to change.
LINE FREQ:
Select the correct AC frequency 50Hz or 60Hz. To select the correct frequency will be
helpful the exact measurement and accuracy. The initial value is 60Hz, the range of control
is "50Hz/60Hz/NA" three choices. Use the keys cursor to select, the block area will move to
right side the "LINE FREQ", then press the keys [50Hz], [60Hz] and [NA] to change. As
the NA is not considerable the frequency of input power, so the speed of test will be faster.
DISPLAY P/F:
To select the scan test result of transformer if use “PASS/NG MODE” for big screen display.
The default setting is “ON”. There are “ON/OFF/SEC./SPC.” 4 ranges for selection. Use
the 4 buttons to move the highlight area to the [ON], [SEC.], [OFF], [SPC] keys at the
right of DISPLAY PIN for selection. The [SEC.] parameter indicates the scan and test are
done at one time. PASS/FAIL screen will disappear after prompted. (The prompt screen does
not affect the test data for observation.) The [SPC.] parameter indicates the prompt screen of
failure is the test parameter with highlight display after the test is completed.
DISPLAY PIN:
To select whether the transformer’s pin position shows on the display of transformer scan
testing. The value is being set on "ON". The selector is "ON/OFF". The procedure is to
move the cursor to the right of the DISPLAY PIN by pressing and adjust it by pressing
[ON] and [OFF].
VOLTAGE M.: (3302 only)
To select whether the output voltage is shown on MEAS. Display of LCR testing. The value
is being set on "OFF". The selector is "ON/OFF". The procedure is to move the cursor to
the right of the VOLTAGE M. by pressing and adjust it by pressing [ON] and [OFF].
