High Power Electronic Load 63200A Series Operation & Programming Manual
2-2
As soon as the instrument is unpacked, inspect any damage that might have occurred in
shipping. Keep all packing materials in case that the instrument has to be returned. If any
damage is found, please file a claim to the carrier immediately. Do not return the instrument
to Chroma without prior approval.
Be sure that the following items listed by respective model are received completely.
Item
Name
Standard Accessories per Model
63205A
63206A
1.
User’s manual CD
1
1
2.
Network cable system bus
2
2
3.
Red/Black test wire
1
1
4.
Power cord 110V
1
1
5.
D-SUB 3 rows 15P
2
2
6.
BNC
2
2
7.
USB
1
1
8.
Screw M6x20L
2
2
9.
Flange nut M4x0.7
2
2
10.
Flange nut M6
2
2
11.
Phillips hex head screw
4
4
12.
Flat washer 4.3*10*0.9-NI
4
4
13.
Spring washer M4
2
2
14.
Flat washer M6
4
4
15.
Spring washer M6
2
2
16.
Mounting bracket (USB)
1
1
17.
Mounting bracket (RJ45)
2
2
18.
Output protective cover
1
1
19.
Protective cover screw M4*8L
4
4
20.
Handle (4U)
2
2
21.
Handle screw M4x10L
8
8
Installing the Communication Interface 2.3
Expansion Slot
The 63200A Series Electronic Load uses GPIB bus (option) to do remote control. The
installation of GPIB card and change of its address as well as the operations are described
in Chapter 4.
CAUTION
Load module can be damaged by electronic discharge (static electricity).
Use standard anti-static work practices when you handle and install
modules. Avoid touching the connector and the circuit board.
Line Voltage 2.3.1
The Electronic Load can operate with a 100-240 Vac input as indicated on the rear LINE
label. The detailed line voltage input range is shown in section 1.4. The Electronic Load can
automatically switch correct line voltage range to correspond to your nominal line voltage,
