Chroma 63200A Series User Manual

Remote Operation
4-59
Query Example: PROG:SEQ:SPEC? 1,V
Return Example: None
SYNCHRONOUS Subsystem 4.3.2.14
SYNChronous:RUN
Type: All Channels
Description: Set all electronic loads to “ON” in sync. dynamic run.
Setting Syntax: SYNChronous:RUN<space><NRf>
Setting Parameters:<NRf>, OFF(0), ON(1)
Setting Example: SYNC: RUN ON Set the load to “ON” on sync. parallel.
SYNC: RUN OFF Set the load to “OFF” on sync. parallel.
SYNChronous:TYPE
Type: All Channels
Description: Set the specified 63200A to master or slave for sync. dynamic run.
Setting Syntax: SYNChronous:TYPE<space><NRf>
Setting Parameters:<NRf>, NONE(0), MASTER(1), SLAVE(2)
Setting Example: SYNC:TYPE MASTER Set the 63200A to master for sync.
dynamic.
SYNC:TYPE SLAVE Set the 63200A to slave for sync.
dynamic.
SYNC:TYPE NONE Disables the 63200A to sync.
STATUS Subsystem 4.3.2.15
STATus:CHANnel:CONDition?
Type: Channel-Specific
Description: Returns the real time channel status.
Query Syntax: STATus:CHANnel:CONDition?
Return Parameters: <NR1>
Bit Configuration of Channel Status Register
Bit Position
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
Condition
MAX_
LIM
RMT
_INH
VCC
FAN
SYNC
OTP
OPP3
OPP2
OPP1
OCP3
OCP2
OCP1
REV
OV2
OV1
Bit Weight
32768
16384
8192
4096
2048
1024
512
256
128
64
32
16
8
4
2
1
Query Example: STAT:CHAN:COND? Return the status of the electronic load.
Return Example: 2048
#3048<byte1><byte2><byte3><byte4><byte5><byte6><byte7><byte8> 、、、
Sequence #1
Sequence #2
Low byte ―――→ High byte
