Chroma 63200A Series User Manual

Operation Overview
3-9
Sub function setup description:
Main Function
Sub Function
Description
Load Setup
Von_POT
Set the start loading voltage.
Von Latch
Lock the start loading voltage.
Von_Voff
Set the voltage to unload.
Short Key
Set short circuit simulation function.
Auto On
Set auto loading at power on.
Measurement
Window T
Set the average measurement time.
Sign of Voltage
Set the voltage sign for display.
Digitizing
Set the data capturing function.
Parallel & Sync.
Address
Set the communication address.
Terminator
Set the terminal resistor.
Sync.
Set the synchronization function.
Parallel
Set the parallel function.
PARA. NUM
Set the parallel number.
INITIAL
Initialization for parallel.
Protection
OCP
Over current protection defined by user.
OPP
Over power protection defined by user.
Remote
GPIB
Set the GPIB communication interface.
Digital I/O
Set the I/O function.
System Setup
Enter Key
Switch to the input parameter.
Sound
Set the button to beep when pressed.
Brightness
Adjust the VFD brightness.
Factory Default
Restore to factory default.
Information
Show the production information.
Calibration
Set the calibration function.
Load Setup 3.5.1
[
C
O
N
F
I
G
.
]
V
o
n
_
P
O
T
=
0
.
0
0
0
V
V
o
n
_
L
A
T
C
H
=
O
F
F
(
0
)
V
o
f
f
_
P
O
T
=
0
.
0
0
0
V
S
H
O
R
T
_
K
E
Y
=
H
O
L
D
(
0
)
A
U
T
O
_
O
N
=
O
F
F
(
0
)
Von_POT, set the start loading voltage level
The current will start loading when the Electronic Load is in Load ON state and the UUT
output voltage reaches the start loading voltage level (Von).
Von_LATCH, lock the start loading voltage
Latch ON means Load will continue loading current when it reaches Von.
Latch OFF means loading current will stop when the UUT voltage is lower than Von.
The Von latch default is OFF.
