CIAT FLOWAY User Manual

EN-31
EN
Check i3
Level 1 access
Supply air fan -
Supply air fan operation check state (C = on; O = off)
Return air fan -
Return air fan operation check state (C = on; O = off)
Fire -
Fire detection sensor check state (F = no fire; O = fire detected)
Rotary heat exchanger -
Rotary heat exchanger operation check state (F = on; O = fault)
Changeover -----
Changeover thermostat state (Cooling or Heating)
Pre-heater -
State of electric pre-heater (F = on without fault, O = off or faulty)
Elect. heater -
State of electric heater heating (F = on without fault, O = off or faulty)
Check i4
Level 1 access
Pump 1 -
Hydraulic coil 1 pump operation check state (F = on, O = off)
Pump 2 -
Hydraulic coil 2 pump operation check state (F = on, O = off)
Humidifier -
Humidifier operation check state (F = on without fault, O = de-energised or faulty)
Elec. heater load shedding
Electric heater load shedding monitoring state (C=No electric heater start-up, O=Electric heater
start-up possible)
Remote control -
Remote control status (C = on; O = off) or "Presence detection"
(C = presence, O = no presence)
2.5.2 Outputs
o1
Level 1 access
Supply air fan ---%
Supply air fan control value
Return air fan ---%
Return air fan control value
Coil 1 Cooling ---%
Water coil No.1 valve control value in "Cooling" mode (or Heating)
Coil 2 Heating ---%
Water coil No.2 valve control value in "Heating" mode (or Cooling)
Wheel speed ---%
Heat exchanger wheel speed control value
o2
Level 1 access
Heat exchanger bypass
Screen visible for "Ceiling-Mounted" or "Vertical" units
---%
Heat exchanger bypass damper opening valve
Control -
Heat exchanger bypass control state ( = open; = closed)
o3
Level 1 access
Faults
Danger -
"Danger" fault summary relay state
Maintenance -
"Maintenance" fault summary relay state
o4
Level 1 access
Damper ---
Unit insulation damper control state
Elec. heater 1 ---
State of electric heaters control 1
Elec. heater 2 ---
State of electric heaters control 2
