CIAT FLOWAY User Manual

EN-55
EN
5.5.2 Variables
The KSet software is supplied for configuring the group addresses, as is the Carel_plugin_21.PR4 file for the ETS3
software (not supplied) and the CDFP2-V22.XML file from the database below:
Description DatapointName
Datapoint
TypeName
Datapoint
TypeCode
IN/OUT
Index
COIL/REG
Supply air filter fouling level
FiltreIntroduction
DPT_Value_Temp
9.001
OUT
1
REG
Supply air duct pressure
PressionGaineIntro
DPT_Value_Temp
9.001
OUT
3
REG
Supply air temperature
TemperatureIntro
DPT_Value_Temp
9.001
OUT
4
REG
Return air temperature
TemperatureExtra
DPT_Value_Temp
9.001
OUT
5
REG
Return air filter fouling level
FiltreExtraction
DPT_Value_Temp
9.001
OUT
7
REG
Heat exchanger fouling
EncrassRecuperateur
DPT_Value_Temp
9.001
OUT
8
REG
Fresh air or outdoor temperature
TemperatureNeuf
DPT_Value_Temp
9.001
OUT
9
REG
Ambient temperature
TemperatureAmb
DPT_Value_Temp
9.001
OUT
10
REG
Air supply fan flow rate
DebitVentilIntro
DPT_Value_Temp
9.001
OUT
11
REG
Return air fan flow rate
DebitVentilExtra
DPT_Value_Temp
9.001
OUT
24
REG
Quality via the unit sensor
QualiteAir
DPT_Value_Temp
9.001
OUT
18
REG
Water coil valve No. 1
Batterie1
DPT_Value_Temp
9.001
OUT
12
REG
Heat exchanger wheel speed
VitesseRecupRotatif
DPT_Value_Temp
9.001
OUT
13
REG
Supply air fan control
VitesseVentilIntro
DPT_Value_Temp
9.001
OUT
14
REG
Return air fan control
VitesseVentilExtra
DPT_Value_Temp
9.001
OUT
15
REG
Water coil valve No. 2
Batterie2
DPT_Value_Temp
9.001
OUT
16
REG
Plate heat exchanger bypass
damper
BipasseRecup DPT_Value_Temp
9.001
OUT
17
REG
Plate heat exchanger insulating
damper
Isolement DPT_Value_Temp
9.001
OUT
25
REG
Mixing damper
Melange
DPT_Value_Temp
9.001
OUT
26
REG
Controlled temperature setpoint
WTemperatureRegul
DPT_Value_Temp
9.001
IN
19
REG
Regulated temperature setpoint
feedback
WTemperatureRegul DPT_Value_Temp
9.001
OUT 19
REG
Supply air duct pressure via a
communicating sensor
PressionGaine DPT_Value_Temp
9.001
IN 22
REG
Return air duct pressure via a
communicating sensor
PressionGaine DPT_Value_Temp
9.001
OUT 22
REG
CO
2
air quality setpoint
WQualiteAir
DPT_Value_Temp
9.001
IN
23
REG
CO
2
air quality setpoint feedback
WQualiteAir
DPT_Value_Temp
9.001
OUT
23
REG
Unit operating state
0 = off
1 = on
2 = on after power failure
3 = standby
4 = off by a fault
5 = off by CMS
6 = post ventilation
EtatUnite
DPT_Value_2_Ucount
7.001
OUT
27
REG
Alarm 1 value:
Bit 0 = Return air filter clogged
Bit 1 = Supply air filter clogged
Bit 2 = Return air filter dirty
Bit 3 = Supply air filter dirty
Bit 4 = Heat recovery unit frosted –
Fouling level monitoring
Bit 5 = Heat recovery unit frosted –
Fresh air temperature check
Bit 6 = Fire
Bit 7 = Return air motor
Bit 8 = Supply air motor
Bit 9 = Rotary heat exchanger
Bit 10 = Clock lithium battery
Bit 11 = Internal hydraulic coil frost
Bit 12 = Duct hydraulic coil frost
Bit 13 = Electric pre-heater
Bit 14 = Electric heater
Bit 15 = Humidifier
Alarme1
DPT_Value_2_Ucount
7.001
OUT
28
REG
Alarm 2 value:
Bit 0 = Sensor B1
Bit 1 = Sensor B2
Alarme2
DPT_Value_2_Ucount
7.001
OUT
29
REG
