EN-47
EN
5.3.4 Variables
5.3.4.1 Controls
Register
hex. no.
Register
decimal
no.
Description Format Type
Registers accessible in read-only mode (functions 1 or 2) for Booleans and write mode
(functions 5 for char or 15)
0x118 280 Remote start/stop control (1 = On) Boolean Read-only/Write
0x119 281 Acknowledging faults (1 = Acknowledgement) Boolean Read-only/Write
0x11A 282 Electric/heater load shedding (1 = Load shedding) Boolean Read-only/Write
0x11B 283
Machine running in Eco/Comfort temperature mode
(0: Comfort/1: Eco)
Boolean Read-only/Write
0x11C 284
Machine running in Eco/Comfort flow rate mode
(0: Comfort/1: Eco)
Boolean Read-only/Write
0x11D 285
Machine running in Eco/Comfort pressure mode
(0: Comfort/1: Eco)
Boolean Read-only/Write
0x11E 286 Standby command Boolean Read-only/Write
0x11F 287 ECO recirculation command Boolean Read-only/Write
0x120 288 "Morning heating" command Boolean Read-only/Write
0x121 289 "Cool night" command Boolean Read-only/Write
5.3.4.2 Setpoints
Register
hex. no.
Register
decimal
no.
Description Format Type
Adjustable
values
Registers accessible in read-only mode (functions 3 or 4) for integers and write mode
(functions 6 for char or 16)
Registers accessible in read-only mode (functions 1 or 2) for Booleans and write mode
(functions 5 for char or 15)
0x0190
400
Supply air Comfort flow rate regulation setpoint Integer Read-only/Write m
3
/h
0x0191
401
Return air Comfort flow rate regulation setpoint Integer Read-only/Write m
3
/h
0x0192
402
Supply air Eco flow rate regulation setpoint Integer Read-only/Write m
3
/h
0x0193
403
Return air Eco flow rate regulation setpoint Integer Read-only/Write m
3
/h
0x0195 405
Nominal pressure control setpoint in the intake
duct
Integer Read-only/Write Pa
0x0196 406
Minimum pressure control setpoint in the intake
duct
Integer Read-only/Write Pa
0x0197 407
Nominal pressure control setpoint in the exhaust
duct
Integer Read-only/Write Pa
0x0198 408
Nominal pressure control setpoint in the exhaust
duct
Integer Read-only/Write Pa
0x019A 410
Regulation setpoint for the monitored Comfort
temperature
Integer Read-only/Write °C x10
0x019B 411
Regulation setpoint for the monitored Eco
temperature
Integer Read-only/Write °C x10
0x1A1
417
Air quality regulation setpoint Integer Read-only/Write ppm
0x1A2 418
Maximum flow rate value of supply air fan for air
quality regulation
Integer Read-only/Write m
3
/h
0x1B2 434 Electric pre-heater stages regulation setpoint Integer Read-only/Write °C x10
0x1B3
435
Temperature setpoint in "Morning heating" mode
Integer
Read-only/Write
°C x10
