CIAT FLOWAY User Manual

EN-53
EN
bit 3
Supply air filter dirty alarm
bit 4
Heat exchanger frost alarm - Clogging detection
bit 5
Heat exchanger frost alarm - Fresh air temperature check
bit 6
Fire alarm
bit 7
Return air motor alarm
bit 8
Supply air motor alarm
bit 9
Rotary heat exchanger alarm
bit 10
Clock lithium battery alarm
bit 11
Internal hydraulic coil frost alarm
bit 12
Hydraulic coil in duct frost alarm
bit 13
Electric Pre-heater alarm
bit 14
Electric Heater alarm
DGT
--
nvo_alarm_17_32
83
SNVT_state
output
Alarm 2 value:
bit 0
B1 sensor alarm
bit 1
B2 sensor alarm
bit 2
B3 sensor alarm
bit 3
B4 sensor alarm
bit 4
B5 sensor alarm
bit 5
B6 sensor alarm
bit 6
IAQ sensor alarm
bit 7
B8 sensor alarm
bit 8
B9 sensor alarm
bit 9
Hydraulic coil 1 pump alarm
bit 10
Hydraulic coil 2 pump alarm
5.4.3 The analogue datapoints
Type
Index NV name
Code
Type
Type
Type
Directio
n
Description
ANL
1
nvo_custom_1
113
SNVT_press_p
output
Supply air filter fouling level
ANL
2
nvo_custom_2
113
SNVT_press_p
output
Supply air duct pressure
ANL
3
nvo_custom_3
113
SNVT_press_p
output
Return air filter fouling level
ANL
4
nvo_custom_4
113
SNVT_press_p
output
Heat exchanger fouling
ANL
8
nvo_custom_8
161
SNVT_flow_p
output
Air supply fan flow rate
ANL
9
nvo_custom_9
161
SNVT_flow_p
output
Return air fan flow rate
ANL
10
nvo_custom_10
29
SNVT_ppm
output
Air quality via the unit sensor
ANL
16
nvo_custom_16
105
SNVT_temp_p
output
Supply air temperature
ANL
17
nvo_custom_17
105
SNVT_temp_p
output
Return air temperature
ANL
18
nvo_custom_18
105
SNVT_temp_p
output
Fresh air or outdoor temperature
ANL
19
nvo_custom_19
105
SNVT_temp_p
output
Ambient temperature
ANL
23
nvo_custom_23
9
SNVT_count_inc
output
Heat exchanger insulating damper position
ANL
24
nvo_custom_24
9
SNVT_count_inc
output
Mixing damper position
ANL
25
nvo_sortie_ana_1
9
SNVT_count_inc
output
Coil 1 valve
ANL
26
nvo_sortie_ana_2
9
SNVT_count_inc
output
Rotary heat exchanger speed
ANL
27
nvo_sortie_ana_3
9
SNVT_count_inc
output
Supply air fan speed
ANL
28
nvo_sortie_ana_4
9
SNVT_count_inc
output
Return air fan speed
ANL
29
nvo_sortie_ana_5
9
SNVT_count_inc
output
Coil 2 valve
ANL
30
nvo_sortie_ana_6
9
SNVT_count_inc
output
Heat exchanger bypass position
ANL
37
nvo_etat_unite
9
SNVT_count_inc
output
Unit operating state:
Value 0
off
Value 1
on
Value 2
switched on after a power failure
Value 3
standby
Value 4
switched off by a fault
Value 5
switched off by CMS
Value 6
post ventilation
ANL
44
nvi_T_regul
105
SNVT_temp_p
input
Regulated temperature setpoint
ANL
44
nvo_T_regul
105
SNVT_temp_p
output
Regulated temperature setpoint feedback
ANL
49
nvi_P_regul
113
SNVT_press_p
input
Supply air duct pressure via a communicating sensor
ANL
49
nvo_P_regul
113
SNVT_press_p
output
Return air duct pressure via a communicating sensor
ANL
50
nvi_Q_regul
29
SNVT_ppm
input
CO
2
air quality setpoint
ANL
50
nvo_Q_regul
29
SNVT_ppm
output
CO
2
air quality setpoint feedback
5.5 KNX
