CIAT FLOWAY - Fan Flow Rate Compensation Based on Outdoor T; Duct Pressure Compensation Based on the Outdoor T; Fan Flow Rate Compensation Based on the Regulated T; Downgraded Fresh Air Flow Rate Function

EN-26
2.4.2 Fan flow rate compensation based on outdoor T°
p8
Level 2 access
030% E -20.0°c
100% F 10.0°c
030% K -20.0°c
100% L 10.0°c
Fig.2
2.4.3 Duct pressure compensation based on the outdoor T°
Fig. 2b
2.4.4 Fan flow rate compensation based on the regulated T°
p9
Level 2 access
G -04.0°c
H -02.0°c
I 02.0°c
J 04.0°c
Reduced 030%
M 04.0°c
N 06.0°c
Fig. 3
2.4.5 "Downgraded fresh air flow rate" function
10
-20
Outdoor T°
100%
30%
Nominal
pressure
10
-20
Outdoor T°
100%
30%
Comfort flow rate
2
-2
-4
4
Regulated T°
100%
Reduce
Comfort flow rate
Setpoint
