CIAT FLOWAY User Manual

EN-30
Calibration ca3
Level 3 access
Dirty filter compensation
Supply air ---Pa
Supply air filter dirty detection threshold compensation
Clogged filter compensation
Supply air ---Pa
Supply air filter clogged detection threshold compensation
Calibration ca4
Level 2 access
Dirty filter compensation
Return air ---Pa
Return air filter dirty detection threshold compensation
Clogged filter compensation
Return air ---Pa
Return air filter clogged detection threshold compensation
Calibration ca5
Level 3 access
Room 00.0°c
Calibration of the room terminal temperature sensor
2.5 Read-only parameters menu
2.5.1 Inputs
i0
Level 1 access
Supply air --.-°c
Supply air temperature value
Return --.-°c
Return air temperature value
Fresh --.-°c
Fresh air temperature value
Room --.-°c
Room air temperature value
Outdoor --.-°c
Outdoor temperature value
i1
Level 1 access
Comfort flow rates
Indicates flow rate type displayed (Comfort, Eco or auto)
Supply air ----m3/h
Supply air fan flow rate value
Return air ----m3/h
Return air fan flow rate value
Comfort duct
Screen visible if Supply air duct pressure regulation selected
Indicates pressure type displayed (Comfort or Eco)
Supply air ----Pa
Supply air duct pressure value
Return air ---Pa
Return air duct pressure value
i1-1
Level 3 access + Prg key
Flow rates
Supply air ----Pa
Supply air fan flow rate value in Pa
Return air ---Pa
Return air fan flow rate value in Pa
i2
Level 1 access
Filters
Supply air ----Pa
Supply air filter fouling value
Return air ---Pa
Return air filter fouling value
Air quality ----ppm
Air quality value in ppm
Heat exchanger ----Pa
Heat exchanger fouling value
