CIAT FLOWAY User Manual

EN-32
o5
Level 1 access
Pump 1 ---
State of hydraulic coil 1 pump control
Pump 2 ---
State of hydraulic coil 2 pump control
Boiler or heat pump ---
State of heat pump or boiler control (Heating or Cooling mode)
Humidifier ---
Humidifier operation authorisation state
o6
Screen visible for "Classic" units (Level 1 Access)
Mixing damper
---%
Mixing damper opening value
Control -
Mixing damper control state ( = opened; = closed)
2.5.3 Setpoints
wc1
Level 1 access
--.-°C
Calculated regulation setpoint for the supply air temperature
Calculated heat exchanger frost
detector
----Pa
Calculated setpoint for heat exchanger frost detection via return air pressure drop measurement
wc2
Level 1 access
Supply air
Filter dirty ---Pa
Calculated setpoint for detection of the supply air "Filter dirty" level
Clogged filter ---Pa
Calculated setpoint for detection of the return air "Filter dirty" level
Return air
Filter dirty ---Pa
Calculated setpoint for detection of the supply air "Filter clogged" level
Clogged filter ---Pa
Calculated setpoint for detection of the return air "Filter clogged" level
2.5.4 Counters
Counters tt1
Level 3 access
Supply air fan
----.-h Reset -
Supply air fan runtime counter reset and time
Counters tt2
Level 3 access
Return air fan
----.-h Reset -
Return air fan runtime counter reset and time
Counters tt3
Level 3 access
Electric heater 1
----.-h Reset -
Electric heaters output 1 runtime counter time and reset
Electric heater 2
----.-h Reset -
Electric heaters output 2 runtime counter time and reset
