Ethernet Port Used to connect to a network using a LAN cable.
USB Port Used to connect to a PC using a USB cable.
USB Socket Used to insert USB memory media or to connect to a PC.
Power Supply Port Connects to the power supply.
Top Cover Lock Key Locks/unlocks the Top Cover.
External RF Recognizes an RF card.
Printer Lock Use this to mount a security lock.
Side Cover Open Section
Press to open the Side Cover.
OPTION
OPTION
OPTION
Name Description
13
CIM User Guide Manual
