Magnetic Cards
If the printer has the MS module (Single/Triple Track Head), it can encode
information on the Mag. Stripe card.. (ISO 7811 track 1,2,3, Hi-Co/Lo-Co)
ISO 7811
Magnetic Card Standard : ISO 7811
Track
Recording Density
Capacity
Start / End code
Track 1 Track 2 Track 3
210 BPI 75 BPI 210 BPI
79 Characters 40 Characters 107 Characters
(7 bit code) (5 bit code) (5 bit code)
%/? ;/? ;/?
When loading Mag. Stripe cards, make sure the magnetic stripe is facing
down and on the left side as shown in the pictures.
28
