4.10.3.7.7. Operating prole
Table 34:Modbus memory map: Operating prole
Operating profile
Configuration variable Address Valid data margin
Default
value
Operating prole 2B60
0: Analyzer
1: User
2: Electrical energy efciency, e
3
0
4.10.3.7.8. Display backlight
Table 35:Modbus memory map: Backlight
Backlight
Configuration variable Address Valid data margin
Default
value
Backlight 2B5E
0: Always lit
5 - 99 seconds
0
4.10.3.7.9. Activating the harmonics display screen
Table 36:Modbus memory map: Display of harmonics
Display of harmonics
Configuration variable Address Valid data margin
Default
value
Display of harmonics 2B62
0: No
1: Yes
1
4.10.3.7.10. CO
2
consumption and generation emissions.
Table 37:Modbus memory map: CO
2
consumption and generation emissions.
CO
2
emissions
Configuration variable
(1)(2)
Address Valid data margin
Default
value
Tariff 1 consumption emissions ratio 2724 0 - 1.9999 0
Tariff 2 consumption emissions ratio 2725 0 - 1.9999 0
Tariff 3 consumption emissions ratio 2726 0 - 1.9999 0
Tariff 1 generation emissions ratio 2728 0 - 1.9999 0
Tariff 2 generation emissions ratio 2729 0 - 1.9999 0
Tariff 3 generation emissions ratio 272A 0 - 1.9999 0
(1)
All variables must be programmed at the same time.
(1)
They have 1 decimal place.
4.10.3.7.11. Cost of energy consumption and generation.
Table 38:Modbus memory map: Cost of energy consumption and generation.
Cost per kWh
Configuration variable
(1)(2)
Address Valid data margin
Default
value
Cost per kWh of tariff 1 consumption 272C 0 - 1.9999 0
Cost per kWh of tariff 2 consumption 272D 0 - 1.9999 0
Cost per kWh of tariff 3 consumption 272E 0 - 1.9999 0
Cost per kWh of tariff 1 generation 2730 0 - 1.9999 0
Cost per kWh of tariff 2 generation 2731 0 - 1.9999 0
Cost per kWh of tariff 3 generation 2732 0 - 1.9999 0
