Cisco 4000 Series User Manual

5-23
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
Chapter 5 Install and Upgrade Internal Modules and FRUs
Remove and Replace Cisco NIM-SSD or NIM-HDD
Restrictions
• Cisco SSD Carrier Card NIM with no SSD drives is not supported.
• Dynamically removing and inserting SSD drives on a NIM is not supported.
• Only a single SSD Carrier Card NIM per router is supported on any bay.
• Replacing any SSD drive can cause some data loss.
Warning During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could shock yourself. Statement 94
Before you begin, read the following:
• The form-factor internal hard drive is accessible from the front panel of the Cisco 4451-X ISR and
supports the online insertion and removal feature (OIR) using the following commands for the
standby:
– request platform hardware filesystem harddisk: offline
– To verify the SSD drive installation, use the show platform command. The following sample
output from a NIM SSD installed on a 4451-X ISR platform:
Router# show platform
Chassis type: ISR4451/K9
Slot Type State Insert time (ago)
--------- ------------------- --------------------- -----------------
0 ISR4452/K9 ok 15:57:33
0/0 ISR4451-6X1GE ok 15:55:24
0/3 NIM-SSD ok 15:55:24
1 ISR4451/K9 ok 15:57:33
1/0 SM-1T3/E3 ok 15:55:24
2 ISR4451/K9 ok 15:57:33
2/0 SM-1T3/E3 ok 15:55:24
R0 ISR4451/K9 ok, active 15:57:33
F0 ISR4451-FP ok, active 15:57:33
P0 Unknown ps, fail never
P1 XXX-XXXX-XX ok 15:56:58
P2 ACS-4450-ASSY ok 15:56:58
Slot CPLD Version Firmware Version
--------- ------------------- ---------------------------------------
0 12090323 15.3(01r)S [ciscouser-ISRRO...
1 12090323 15.3(01r)S [ciscouser-ISRRO...
2 12090323 15.3(01r)S [ciscouser-ISRRO...
R0 12090323 15.3(01r)S [ciscouser-ISRRO...
F0 12090323 15.3(01r)S [ciscouser-ISRRO...
• You remove an internal hard drive only when it fails. You can remove the internal drive and recover
the data.
• If the drive is in active state, you can back up with the drive plugged into a USB port using the
archive tar command.
