3-17

Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers

OL-32185-02

Chapter 3 Install and Connect Cisco 4000 Series ISRs

Install the Router

Figure 3-11 AC Power Bracket Installation for Left Mounting (Cisco 4221 ISR shown)

1 Mounting Screws 2 AC power supply unit installation module

3 23-inch SBC brackets 4 19-inch SBC brackets

385355
