Cisco 4000 Series - Platform Summary

1-25
Hardware Installation Guide for the Cisco 4000 Series Integrated Services Router
OL-32185-02
Chapter 1 Overview of Cisco 4000 Series ISRs
Chassis Views
Figure 1-29 LEDs on Cisco 4221 ISR
For detailed information on LEDs, see the “LED Indicators” section on page 1-29.
Platform Summary
Figure 1-30 shows the internal view of Cisco 4221 ISR with parts and module locations.
Figure 1-30 Platform Summary of Cisco 4221 ISR Chassis
1 LEDs
1
365771
5
4
2
3
365772
1
