Cisco 4000 Series User Manual

3-27
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
Chapter 3 Install and Connect Cisco 4000 Series ISRs
Connect WAN, LAN, and Voice Interfaces
Step 5 Click Finish.
Uninstall Cisco Microsoft Windows Vista USB Driver
Note Disconnect the router console terminal before uninstalling the driver.
Step 1 Run the setup.exe for Windows 32-bit or setup(x64).exe for Windows-64bit. Click Next.
The InstallShield Wizard for Cisco Virtual Com appears.
Step 2 Click Next The Program Maintenance window appears.
Step 3 Select the Remove radio button and click Next. The Remove the Program window appears.
Step 4 Click Remove. The InstallShield Wizard Completed window appears.
Note If a User Account Control warning appears, click “Allow - I trust this program...” to proceed.
Step 5 Click Finish.
Connect WAN, LAN, and Voice Interfaces
• Ports and Cabling, page 3-28
• Connection Procedures and Precautions, page 3-29
Warning Do not work on the system or connect or disconnect cables during periods of lightning activity.
Statement 1001
Warning To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network
voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some
LAN and WAN ports both use RJ-45 connectors. Use caution when connecting cables. Statement 1021
Warning Hazardous network voltages are present in WAN ports regardless of whether power to the unit is OFF
or ON. To avoid electric shock, use caution when working near WAN ports. When detaching cables,
detach the end away from the unit first. Statement 1026
Caution To comply with the Telcordia GR-1089 NEBS standard for electromagnetic compatibility and safety,
connect Gigabit Ethernet ports using RJ-45 connectors for shielded twisted pair cable only to
intra-building or unexposed wiring or cable. The intra-building cable must be shielded and the shield
must be grounded at both ends. The intra-building port(s) of the equipment or subassembly must not be
