Cisco 4000 Series - Remove the SSD Msata Storage Device

5-74
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
Chapter 5 Install and Upgrade Internal Modules and FRUs
Install and Remove an SSD mSATA Storage Device
Step 6 Replace the chassis cover. See “Remove and Replace Chassis Cover” section on page 5-4.
Remove the SSD mSATA Storage Device
Step 1 Read the “Safety Warnings” section on page 5-2, and disconnect the power supply before you replace
any module.
Step 2 Remove the chassis cover. For instructions on removing the chassis cover, see “Remove and Replace
Chassis Cover” section on page 5-4.
Step 3 Unscrew the screws that attach the SSD mSATA storage device to the chassis. See Figure 5-54.
Step 4 The card should popup after the screws are removed.
Step 5 Install a new SSD mSATA memory device if needed. See Install the SSD mSATA Storage Device,
page 5-73.
Step 6 Replace the chassis cover. See “Remove and Replace Chassis Cover” section on page 5-4.
1 Supplied screw 2 Supplied screw
3 Flash memory card 4 SSD mSATA storage device
5 Flash memory card connector 6 SSD mSATA connector
