Cisco 4000 Series

To Next Page

To Previous Page

5-46

Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers

OL-32185-02

Chapter 5 Install and Upgrade Internal Modules and FRUs

Remove and Replace Cisco 4000 Series ISRs Power Supplies

Figure 5-36 DC Power Supply

1 Handle 2 FAIL and OK LEDs

3 DC power connector 4 Ejector latch

1 3

371154
