5-62

Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers

OL-32185-02

Chapter 5 Install and Upgrade Internal Modules and FRUs

Replace a Fan Tray

Figure 5-48 Cisco 4461 ISR4 Fan Tray

Figure 5-49 Cisco 4351 ISR4 Fan Tray

1 Fan tray 2 Captive screws

391825

1 Captive screws 2 Fan tray
