CHAPTER
3-1
Hardware Installation Guide for Cisco 4000 Series Integrated Services Routers
OL-32185-02
3
Install and Connect Cisco 4000 Series ISRs
This chapter describes how to install and connect Cisco 4000 Series Integrated Services Routers (ISRs)
to LAN, WAN, and Voice networks. The following sections provide technical details.
• Install the Router, page 3-4
• Chassis Grounding, page 3-19
• Connect Power, page 3-20
• Connect to Console Terminal or Modem, page 3-22
• Install Cisco Microsoft Windows USB Device Driver, page 3-24
• Uninstall Cisco Microsoft Windows USB Driver, page 3-26
• Connect WAN, LAN, and Voice Interfaces, page 3-27
Warning To see translations of the warnings that appear in this publication, see the Regulatory Compliance and
Safety Information for the Cisco 4000 Series ISRs document.
Only trained and qualified personnel
should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
This unit might have more than one power supply connection. All connections must be removed to
de-energize the unit.
Statement 1028
Warning
Blank faceplates and cover panels serve three important functions: they prevent exposure to
hazardous voltages and currents inside the chassis; they contain electromagnetic interference (EMI)
that might disrupt other equipment; and they direct the flow of cooling air through the chassis. Do not
operate the system unless all cards, faceplates, front covers, and rear covers are in place.
Statement
1029
Warning
Hazardous network voltages are present in WAN ports regardless of whether power to the unit is OFF
or ON. To avoid electric shock, use caution when working near WAN ports. When detaching cables,
detach the end away from the unit first.
Statement 1026
