1-14
Cisco ASA Series CLI Configuration Guide
Appendix 1 Configuring an External Server for Authorization and Authentication
Configuring an External LDAP Server
URL Types Supported in ACLs
The URL may be a partial URL, contain wildcards for the server, or include a port.
The following URL types are supported.
Note The URLs listed in this table appear in CLI or ASDM menus based on whether or not the
associated plug-in is enabled.
Guidelines for Using Cisco-AV Pairs (ACLs)
• Use Cisco-AV pair entries with the ip:inacl# prefix to enforce access lists for remote IPsec and SSL
VPN Client (SVC) tunnels.
• Use Cisco-AV pair entries with the webvpn:inacl# prefix to enforce access lists for SSL VPN
clientless (browser-mode) tunnels.
• For webtype ACLs, you do not specify the source because the ASA is the source.
Table 1-4 Examples of Cisco AV Pairs and Their Permitting or Denying Action
Cisco AV Pair Example Permitting or Denying Action
ip:inacl#1=deny ip 10.155.10.0 0.0.0.255
10.159.2.0 0.0.0.255 log
Allows IP traffic between the two hosts using a full
tunnel IPsec or SSL VPN client.
ip:inacl#2=permit TCP any host
10.160.0.1 eq 80 log
Allows TCP traffic from all hosts to the specific host
on port 80 only using a full tunnel IPsec or SSL VPN
client.
webvpn:inacl#1=permit url
http://www.example.com
webvpn:inacl#2=deny url smtp://server
webvpn:inacl#3=permit url
cifs://server/share
Allows clientlessSSL VPN traffic to the URL
specified, denies SMTP traffic to a specific server,
and allows file share access (CIFS) to the specified
server.
webvpn:inacl#1=permit tcp 10.86.1.2 eq
2222 log
webvpn:inacl#2=deny tcp 10.86.1.2 eq
2323 log
Denies Telnet access and permits SSH access on
non-default ports 2323 and 2222, respectively, or
other application traffic flows using these ports for
clientless SSL VPN.
webvpn:inacl#1=permit url
ssh://10.86.1.2
webvpn:inacl#35=permit tcp 10.86.1.5 eq
22 log
webvpn:inacl#48=deny url
telnet://10.86.1.2
webvpn:inacl#100=deny tcp 10.86.1.6 eq
23
Allows clientless SSL VPN SSH access to default
port 22 and denies Telnet access to port 23,
respectively. This example assumes that you are using
Telnet or SSH Java plug-ins enforced by these ACLs.
any All URLs https:// post:// ssh://
cifs:// ica:// rdp:// telnet://
citrix:// imap4:// rdp2:// vnc://
citrixs:// ftp:// smart-tunnel://
http:// pop3:// smtp://
