DETAILED STEPS
PurposeCommand or Action
configure
Step 1
Specifies the autonomous system number of the
routing process to configure an EIGRP routing
process.
router eigrp as-number
Example:
RP/0/RSP0/CPU0:router(config)# router eigrp 100
Step 2
Enters a VRF address family configuration mode.address-family { ipv4 | ipv6 }
Example:
RP/0/RSP0/CPU0:router(config-eigrp)# address-family
ipv4
Step 3
Configures the interface on which EIGRP the routing
protocol runs.
interface type interface-path-id
Example:
RP/0/RSP0/CPU0:router(config-eigrp-af)#
Step 4
interface gigabitEthernet 0/1/5/0
Authenticates all EIGRP protocol traffic on the
interface, based on the MD5 algorithm.
authentication keychain keychain-name
Example:
RP/0/RSP0/CPU0:router(config-eigrp-af-if)#
authentication keychain
Step 5
commit
Step 6
Configuring an Authentication Keychain for an IPv4/IPv6 Interface on a Nondefault VRF
Perform this task to configure an authentication keychain for an IPv4/IPv6 interface on a nondefault VRF.
SUMMARY STEPS
1.
configure
2.
router eigrp as-number
3.
vrf vrf-name
4.
address-family { ipv4 | ipv6 }
5.
interface type interface-path-id
6.
authentication keychain keychain-name
7.
commit
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
330
Implementing EIGRP
Configuring an EIGRP Authentication Keychain
