Named Form for Extcommunity-set Bandwidth
A bandwidth set provides link bandwidth extended community attribute support to perform unequal load
balancing for multi-homed sites.
extcommunity-set bandwidth extcomm-bw
100:25000
end-set
The demilitarized zone (DMZ) link-bandwidth value is configured using outbound route-policy using routing
table or adding the additive keyword. Else, this will lead to the routes-not-imported condition at the receiving
end of the peer.
extcommunity-set bandwidth dmz_ext
1:8000
end-set
!
route-policy dmz_rp_vpn
set extcommunity bandwidth dmz_ext additive <<< 'additive' keyword.
pass
end-policy
These options are supported under extended community set Bandwidth:
RP/0/RSP0/CPU0:router(config)# extcommunity-set bandwidth extcomm-bw
RP/0/RSP0/CPU0:router(config-ext)# ?
#-remark Remark beginning with '#'
<1-65534> 16-bit decimal number
AS-TRANS ASN23456
ASN:N extended community - ASPLAIN format
abort Discard RPL definition and return to top level config
end-set End of set definition
exit Exit from this submode
show Show partial RPL configuration
DescriptionOption
Remark beginning with '#'#-remark
Wildcard (any community or part thereof)*
16-bit decimal number<1-65535>
ASN23456 (reserved ASN)AS-TRANS
Extended community - ASPLAIN format, where ASN
is AS number and N is bandwidth value.
ASN:N
Discard RPL definition and return to top level configabort
End of set definitionend-set
Exit from this submodeexit
Show partial RPL configurationshow
prefix-set
A prefix-set holds IPv4 or IPv6 prefix match specifications, each of which has four parts: an address, a mask
length, a minimum matching length, and a maximum matching length. The address is required, but the other
three parts are optional. The address is a standard dotted-decimal IPv4 or colon-separated hexadecimal IPv6
Cisco ASR 9000 Series Aggregation Services Router Routing Configuration Guide, Release 5.3.x
550
Implementing Routing Policy
Routing Policy Language Overview
