Cisco ASR 1001-X User Manual

DETAILED STEPS
Step 1
To insert a SPA, locate the guide rails that hold the SPA in place. They are at the top left and top right of the SPA slot
and are recessed about an inch.
Step 2
Carefully slide the SPA all the way in using both hands until the SPA is firmly seated in the SPA interface connector.
When fully seated, the SPA might be slightly behind the faceplate.
Step 3
After the SPA is properly seated, fasten the SPA in place with the captive installation screws on either side of the SPA.
Ensure that you fasten the captive installation screws to provide appropriate connectivity.Note
Step 4
Restart the SPA using the following steps:
a) At the router# prompt, enter hw-module subslot 0/1 start and press Enter.
b) At the router# prompt, enter end and press Enter.
Step 5
Use the show platform command to verify whether the status of subslot 0/1 is OK.
show platform Command
Example:
Router# show platform
Chassis type: ASR1001-X
Slot Type State Insert time (ago)
--------- ------------------- --------------------- -----------------
0 ASR1001-X ok 00:34:05
0/0 BUILT-IN-2T+6X1GE ok 00:33:14
0/1 SPA-4XT-SERIAL ok 00:33:14
0/2 NIM-SSD ok 00:33:11
R0 ASR1001-X ok 00:34:05
R0/0 ok, active 00:34:05
R0/1 ok, standby 00:32:47
F0 ASR1001-X ok, active 00:34:05
P0 ASR1001X-PWR-AC ps, fail 00:33:44
P1 ASR1001X-PWR-AC ok 00:33:42
P2 ASR1001-X-FANTRAY ok 00:33:47
Slot CPLD Version Firmware Version
--------- ------------------- ---------------------------------------
0 14041015 15.4(2r)S
R0 14041015 15.4(2r)S
F0 14041015 15.4(2r)S
You have completed the Cisco ASR 1001-X Router SPA replacement procedure.
Removing and Replacing a NIM on the Cisco ASR 1001-X Router
The OIR feature allows you to install and replace a NIM while the router is operating. You do not have to
shut down the system’s power although you should not run traffic through the NIM while it is being removed.
OIR is a method that is seamless to end users on the network, and maintains all routing information and
preserves sessions.
As you disengage the NIM from the router, OIR shuts down all the active interfaces in the NIM.Note
We recommend that you have the following tools and parts readily available for installing a NIM:
Cisco ASR 1001-X Router Hardware Installation Guide
111
Removing and Replacing FRUs from the Cisco ASR 1001-X Router
Removing and Replacing a NIM on the Cisco ASR 1001-X Router

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
