Cisco ASR 1013 Router Memory and Storage Options
Table 48: Memory and Storage Options for Cisco ASR 1013 Router
Maximum System SupportDefaultMemory Type
8 GB8 GB
R21– DRAM
2 GB1 GB for ASR1000-ESP-5
2 GB for ASR1000-ESP10
FECP – DRAM
8 GB – Not Field Upgradeable
8 GB on the integrated RP on the Cisco
ASR 1002 Router (partitioned: 1 GB for
bootflash; 7 GB for mass storage)
eUSB – Internal Flash + NVRAM
Cisco ASR 1013 Router Ethernet RJ-45 Port Pinouts
The Cisco ASR 1013 Router has RJ-45 port for the 10/100/1000 Ethernet connections. The RJ-45 port supports
IEEE 802.3ab (Gigabit Ethernet) and IEEE 802.3u (Fast Ethernet) interfaces compliant with 10BASET,
100BASETX, and 1000BASET specifications.
The RJ-45 port supports standard straight-through and crossover Category 5 UTP cables with RJ-45 connectors.
Cisco does not supply Category 5 UTP cables; these cables are available commercially.
Cisco ASR 1013 Router MGMT Ethernet Port Signals and Pinouts
Table 49: Management Ethernet 10/100/1000 RJ-45 Port Pinouts for Cisco ASR 1013 Router
DescriptionDirectionSignalPin
Transmit DataOutputTX Data+1
Transmit DataOutput
TX Data–
2
Receive DataInputRX Data+3
——
NC4, 5
Receive DataInput
RX Data–
6
——
NC7,8
Cisco ASR 1001-X Router Hardware Installation Guide
135
Cisco ASR 1001-X Router Specifications
Cisco ASR 1013 Router Memory and Storage Options

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
