SPARENormally Closed
(NC)
Normally Open
(NO)
Common
(CM)
DescriptionSignal
—
18619Critical Visual
Alarm
CRTVA
—
2078Major Visual
Alarm
MAJVA
—
21922Minor Visual
Alarm
MINVA
10, 11, 12, 13,
23, 24, 25
———SPARE—unused
pin reserved for
future use
SPARE
Cisco ASR 1001-X Router Specifications
Table 54: Cisco ASR 1001-X Router Specifications , on page 138 lists the Cisco ASR 1001-X Router physical
specifications.
The Cisco ASR 1001-X Router has the route processor, embedded services processor, and SIP integrated
in the chassis.
Note
Table 54: Cisco ASR 1001-X Router Specifications
SpecificationDescription
Height—1.71 in. (43.43 mm)
Width—17.3 in. (439.42 mm)
Depth—22.50 in. (571.5 mm) including card handles,
cable-management brackets, and power supply
handles)
Dimensions (H x W x D)
25 lb fully loadedWeight
0° to 40° CNominal operating temperature
0° to 50° CShort-term operating temperature
10 to 90% relative humidityNominal operating humidity
5 to 90%Short-term operating humidity
–20° to +70° C
Storage temperature
Cisco ASR 1001-X Router Hardware Installation Guide
138
Cisco ASR 1001-X Router Specifications
Cisco ASR 1001-X Router Specifications

Cisco ASR 1001-X Specifications

General

Product color	Gray
Rack capacity	1U
Rack mounting	Yes
Networking standards	-
Ethernet LAN (RJ-45) ports	6
Installed SFP modules quantity	2
Flash memory	1024 MB
Internal memory	8192 MB
Processor cores	4
AC input voltage	85 - 264 V
Power source type	AC
Power consumption (typical)	250 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	5 - 90 %
Security algorithms	AES

Weight and Dimensions

Depth	461.5 mm
Width	439.42 mm
Height	43.43 mm
Weight	10590 g
